Application(s): 1990 to 1996 Nissan 300ZX VG30DE and VG30DETT motors with the OEM distributorless ignition.

Level of control: Full Standalone EMS– Fuel and Ignition Control

The cam angle sensor has often been a bit of an issue for MegaSquirt, but now with MS3’s new V1.1 code, you don’t have to disassemble the CAS for an alternate trigger wheel – you can use all stock hardware!

ECU Modifications

We recommend the MegaSquirt-III for its support of the stock cam angle sensor.

Wiring

Usually, the MS3 uses pin 32 for the cam input signal. Because of the high frequency of the stock CAS, you’ll be using PT4 (pin 31) instead.

CAS pin out

You will also need to connect 1K ohm, 1/4 watt resistors from TPS VREF (pin 26) to both the low resolution signal and the high resolution signal to provide a pull-up in the wiring harness.

For the fuel and spark outputs, use the following pins. You can wire the MS3X outputs to the stock ignition module; it will not drive the coils directly.

These engines use PWM idle control and boost control, both of which can be done using the MS3X medium current outputs.

TunerStudio Configuration for MS-III

Under the ignition setup menu, set the following.

• Spark mode: Nissan RB25 (We’ve confirmed the VG30DE / DETT CAS has the same pattern)
• Trigger Angle / Offset: 0 (adjust as needed if your timing doesn’t line up)
• Ignition input capture: Rising edge
• Spark output: Going High / Inverted if using stock ignition module
• Number of coils: Coil on plug
• Spark hardware in use: MS3X spark
• Cam input: MS3X

If you use someone else’s .msq file we do recommend you check the firmware version the .msq file was built on as you cannot always use a file built on one firmware version with an ECU running a different version– it’s best to use the .msq files with the same version of the firmware that the file was built on. Alternately you can manually copy the settings over from the borrowed file.

Suggested parts

As stated above, we recommend a MegaSquirt-III V3.0 or V3.57 to have full control over the engine. You will be able to use your existing sensors except for the MAP sensor which is built into the MegaSquirt.

ECU options:

• MegaSquirt-III V3.0 kit and MS3X
• MegaSquirt-III V3.57 assembled unit with MS3X

Other recommended parts

• JimStim Stimulator kit or assembled JimStim
• 12′ wiring harness and 12′ MS3X add on harness (8′ also available)

If you haven’t already, please read the ‘disclaimer’ at the top of the parent page here.
Updated 1/16/2014

Taking control of the timing

The PerTronix Ignitor is a small, self contained ignition module that replaces breaker points. PerTronix also offers ready to run distributors that come equipped with the Ignitor. If you are using the distributor advance mechanism to control the timing, you can simply follow the directions for fuel only and triggering off the negative terminal of the coil. This article covers the other possibility: locking out the distributor and having the MegaSquirt control timing. When you do this, the PerTronix functions as a sensor for the MegaSquirt, with the MegaSquirt firing the coil. Although the Ignitor uses a Hall effect sensor, it is not possible to wire MegaSquirt to this sensor directly. You’ll need to use the ignition control output instead.

First, you will need to lock out the distributor. With PerTronix’s own distributor line, they have a simple lock-out kit; use part number D703700 for counter-clockwise rotating distributors and part number D9010 for clockwise rotating distributors. For OEM points distributors, how to lock it out will depend on the distributor and may require welding parts together.

Once the distributor is locked out, you will want to adjust the distributor so the Ignitor would fire the coil somewhere between 1 and 19 degrees BTDC, and have the distributor rotor aligned so the center of its tip points at the #1 distributor cap tower at around 20 to 30 degrees BTDC. This is called distributor phasing, and is important to be sure the spark can travel to the spark plugs when the coil fires.

Note that MegaSquirt will not work with the Ignitor III, either in fuel only or using it as a trigger for MegaSquirt controlled ignition. The problem is that the Ignitor III sends multiple spark signals per ignition event, and does not have a tach output with a single pulse per ignition event. This prevents it from providing a usable signal to trigger the MegaSquirt or other electronics. As PerTronix’s Ignitor III documentation notes, “We recommend the Ignitor or Ignitor II as a trigger source for a capacitive discharge box“, (bolt printing in the original) and the same warning applies to using the Ignitor III as a trigger for MegaSquirt or other EFI controllers.

Using the MegaSquirt-I (MS1/Extra)

This is a straightforward option with a V3.0 or V3.57 board.

MegaSquirt-I PCBv3.0 Mods Required:

• Build the VR conditioner circuit, as described in MSExtra’s MS1 Manual. All our preassembled Megasquirts with the V3.0 board come with this circuit installed.
• Jumper TachSelect to VRIN.
• Jumper TSEL to VROUTINV.
• You may need to adjust the VR trim pots, R52 and R56, when this is installed on a running engine. A usual base setting is to turn them all the way counterclockwise, then give both a half turn clockwise.
• Jumper IGBTOUT to IGN to send to IGBT ignition coil driver signal out of pin 36 on the DB37.
• Cut out R57 if fitted (This won’t be there on my units, though.).
• Get a 330 ohm 1/4w resistor and cut the leads down to about 1/2″ at each end. Maybe a bit less.
• Tin each end of the resistor with a bit of solder.
• Cut a 5″ piece of hookup wire (22ga is fine) and strip just a 1/8″ or so. Tin the stripped wire with solder.
• Melt the tinned wire tip to one end of the tinned 330 ohm resistor tip and let it cool.
• Heatshrink wrap this wire/resistor assembly.
• Use this wire/resistor combo to jumper the ‘top’ (top as in when you facing the silkscreen side of the PCB, with the text so that you can read it normally) lead of R26 to IGBTIN on the opposite side of the PCB.

That’s it!
